Author Topic: Replacement Front Wing Fitment?  (Read 17558 times)

0 Members and 1 Guest are viewing this topic.

Offline prid

  • Newbie
  • Posts: 14
  • Respect 0
  • Gender: Male
    • Cally 16v Ecotec
Replacement Front Wing Fitment?
« on: June 14, 2011, 22:34:57 PM »
Hi all

I have found a new wing for my calbra  :) ;) :).

So my next question is how do i change the wing ? Also due to the dent in the wing, the door will not open  more than an 1" to 2"  :-\ :-\ is this going to be a problem ??? ??? :-\ :-\ .

Does any one have any pics on how to do it  ???

Thanks very much for the help  :) :) :)

Offline ALZ1307

  • * ClubCalibra VIP *
  • *
  • Posts: 26575
  • Respect 11
  • Gender: Female
    • Cally 2.5i v6
Re: Replacement Front Wing Fitment?
« Reply #1 on: June 14, 2011, 22:49:42 PM »
Title amended, please don't use caps lock.

As far as I know it's a bolt on part, you'll probably have to remove front bumper I would assume and wheel arch liner to access all the bolts. Not done it myself on a Cally but should be fairly easy I would of thought.
Lewis Hamilton said that winning his first race felt better than having sex. Kimi's reply to that was, Maybe he never had sex.

Offline sealeysonic

  • Calibra Mentor
  • Posts: 5855
  • Respect 7
  • Gender: Male
    • Cally SE
Re: Replacement Front Wing Fitment?
« Reply #2 on: June 14, 2011, 23:15:03 PM »
Yup itS just bolted on.....theres about 8 on the top edge of the wing with the bonnet up....then one bolt down the bottom front near the bumper...then pne more near the bottom of the door(wich means you might have to removed the side skirts)

Offline Phil.

  • Calibra Mentor
  • Posts: 7262
  • Respect 0
  • Gender: Male
    • Other Brand
Re: Replacement Front Wing Fitment?
« Reply #3 on: June 14, 2011, 23:23:35 PM »
There's also one inside the door shut which can be a bluddy nightmare. You'll need your door open for it so even if you have to mangle the existing wing to get it open it will be necessary.
Audi S4 2.7 Twin Turbo Avant, RS4 Turbo's + Intake, 2.5'' Turbo's Back Exhaust, Fully Rebuilt Cylinder Heads, RS4 Fuel Pump + Injectors, Coilovers, RS6 Seats, 18'' B6 Alloys, RS4 360mm Fronts, RS4 321mm vented rears, RS4 Spoiler, much more!

Offline prid

  • Newbie
  • Posts: 14
  • Respect 0
  • Gender: Male
    • Cally 16v Ecotec
Re: Replacement Front Wing Fitment?
« Reply #4 on: June 15, 2011, 17:13:26 PM »
There's also one inside the door shut which can be a bluddy nightmare. You'll need your door open for it so even if you have to mangle the existing wing to get it open it will be necessary.

Where abouts is this bolt  ?? if its at he top i may get away with it.

Thanks for the help


Offline DanSE4

  • Calibra Mentor
  • Posts: 17169
  • Respect 11
  • Gender: Male
    • Cally 3.2i v6
Re: Replacement Front Wing Fitment?
« Reply #5 on: June 15, 2011, 17:17:13 PM »
Where abouts is this bolt  ?? if its at he top i may get away with it.

Thanks for the help



It is at the top, just below the level of the wing mirror. It can be removed without damaging anything, I've done it several times (last time was less than 2 weeks ago).

Open the door fully & you'll see it.
Calibra SE4 3.2 V6 & F28 - On-going project.
BMW E91 320d Daily "w*nker" Car
The Missis's BMW E90 330i "w*nkerette" Car

Offline prid

  • Newbie
  • Posts: 14
  • Respect 0
  • Gender: Male
    • Cally 16v Ecotec
Re: Replacement Front Wing Fitment?
« Reply #6 on: June 15, 2011, 17:21:58 PM »
It is at the top, just below the level of the wing mirror. It can be removed without damaging anything, I've done it several times (last time was less than 2 weeks ago).

Open the door fully & you'll see it.

Thats the prob. I can only open the door by about 1" to 2" because of the dent in the wing.

thanks


Offline DanSE4

  • Calibra Mentor
  • Posts: 17169
  • Respect 11
  • Gender: Male
    • Cally 3.2i v6
Re: Replacement Front Wing Fitment?
« Reply #7 on: June 15, 2011, 17:26:20 PM »
As Phil said then, you may have to remove every other bolt first to bend the f*ck out of it to get the door open!
Calibra SE4 3.2 V6 & F28 - On-going project.
BMW E91 320d Daily "w*nker" Car
The Missis's BMW E90 330i "w*nkerette" Car

Offline zxr2

  • Calibra Pro
  • Posts: 677
  • Respect 0
  • Gender: Male
    • Cally 2.0i 8v
Re: Replacement Front Wing Fitment?
« Reply #8 on: June 16, 2011, 00:13:41 AM »


the picture above shows the two bolt holes under the front bumper



the arrow A just shows the direction of the front of the wing this part of the wing you can see in the doorshut, bolt B is the pain to get at its behind the the panel next to the accelerator pedal just above the engine ecu



this bolt above is at the top of the wing you will have to get the door open to undo this one i might be slightly covered buy the windscreen rubber/doorshut rubber





this bolt you have to remove the plastic valence under the doorsill you can get away with probably undoing the front bolts then holding it down to get at this one

the bolts on the top of the wing you can get at buy opening the bonnet  hope this helps regards harry

Offline DanSE4

  • Calibra Mentor
  • Posts: 17169
  • Respect 11
  • Gender: Male
    • Cally 3.2i v6
Re: Replacement Front Wing Fitment?
« Reply #9 on: June 16, 2011, 08:35:31 AM »
bolt B is the pain to get at its behind the the panel next to the accelerator pedal just above the engine ecu

Can't believe no-one else (myself included) remembered to mention that one. I had a fight with the wing the first time I removed one until I found that bolt on the inside!

Helpful post dude! :)
Calibra SE4 3.2 V6 & F28 - On-going project.
BMW E91 320d Daily "w*nker" Car
The Missis's BMW E90 330i "w*nkerette" Car

Offline zxr2

  • Calibra Pro
  • Posts: 677
  • Respect 0
  • Gender: Male
    • Cally 2.0i 8v
Re: Replacement Front Wing Fitment?
« Reply #10 on: June 16, 2011, 11:54:11 AM »
Can't believe no-one else (myself included) remembered to mention that one. I had a fight with the wing the first time I removed one until I found that bolt on the inside!

Helpful post dude! :)

no probs this is what the site is all about   ;)

Offline prid

  • Newbie
  • Posts: 14
  • Respect 0
  • Gender: Male
    • Cally 16v Ecotec
Re: Replacement Front Wing Fitment?
« Reply #11 on: June 16, 2011, 18:11:43 PM »

the picture above shows the two bolt holes under the front bumper

[
the arrow A just shows the direction of the front of the wing this part of the wing you can see in the doorshut, bolt B is the pain to get at its behind the the panel next to the accelerator pedal just above the engine ecu


this bolt above is at the top of the wing you will have to get the door open to undo this one i might be slightly covered buy the windscreen rubber/doorshut rubber




this bolt you have to remove the plastic valence under the doorsill you can get away with probably undoing the front bolts then holding it down to get at this one

the bolts on the top of the wing you can get at buy opening the bonnet  hope this helps regards harry

Cool thanks for the help and the pics.


Offline carl

  • Calibra Mentor
  • Posts: 11731
  • Respect 1
  • Gender: Male
    • Cally 16v Redtop
Re: Replacement Front Wing Fitment?
« Reply #12 on: June 16, 2011, 18:36:03 PM »
Yup itS just bolted on.....theres about 8 on the top edge of the wing with the bonnet up....then one bolt down the bottom front near the bumper...then pne more near the bottom of the door(wich means you might have to removed the side skirts)

and one near the wing mirror when you open the door, and one on the inside of the wing behind all the sound deadining stuff
bodybuilding thread! the thread for winners!
http://www.clubcalibra.com/index.php?topic=34651.msg449718#msg449718
**Carl's calibra project**
http://www.clubcalibra.com/index.php?topic=34701.msg450951#msg450951
You argued with an idiot, I brought you down to my level and I beat you with experience.

Offline prid

  • Newbie
  • Posts: 14
  • Respect 0
  • Gender: Male
    • Cally 16v Ecotec
Re: Replacement Front Wing Fitment?
« Reply #13 on: June 27, 2011, 21:07:20 PM »
Hi All

My Calibra is back on the road  :) :) 8) 8) :) :) 8) 8) 8) 8) 8) 8) :) :) :) :) :) 8) ;D ;D ;D ;D ;D ;D ;D ;D ;D ;D ;D ;D.

So a big thank you to you all for the help,couldn't of done it with out you  :) :) :) ;) ;) ;D 8) 8) 8) ;) :) :) :) :)

 :) :)

Offline sealeysonic

  • Calibra Mentor
  • Posts: 5855
  • Respect 7
  • Gender: Male
    • Cally SE
Re: Replacement Front Wing Fitment?
« Reply #14 on: July 03, 2011, 09:47:58 AM »
Great news.......yaaaay
